商品の詳細:
|
| プレートタイプ: | 波紋紙 | 重さ: | 3000kg |
|---|---|---|---|
| 製品名: | 波形のカートン箱機械 | 容量: | 50-100pcs/min |
| 保証: | 1年 | 応用: | 包装業界 |
| 制御システム: | plc | 力: | 220V/380V |
| ハイライト: | 220V corrugated carton box machine,380V carton box making machine,industrial corrugated box machine with warranty |
||
| Diameter | Φ215mm |
|---|---|
| Processing Way | Surface of glue roller is grinded, then with 25 line rut type net dot, then plating chrome. Surface of glue balance roller is grinded then plating chrome |
| Control Way | Cylinder control of the Lifting Up-down |
| Glue Supply | Glue circulating system (storage tank+glue pump) |
| Diameter | Down Roller: Φ280mm |
|---|---|
| Material | 48CrMo high quality alloy steel, rigidity HRC55°-58° |
| Processing Way | The surface of upper-lower roller is plating chrome, annealing, hardening and tempering, surface grinded |
| Flute Type | (U/V) ACBEF |
| Heating way of the reel paper | Electric heating |
| Diameter | Φ280mm |
|---|---|
| Material | Medium steel (MS)45# |
| Processing Way | The surface is grinded then plating chrome, hardening and tempering (With Buffer) |
| Control Way | Cylinder control of the Lifting Up-down |
| Diameter | UP Roller: Φ320mm |
|---|---|
| Material | Seamless steel tube |
| Material band or origin | Tianjin Iron & Steel |
| Connection | All connected by flexible metallic tubes |
| Style of Transmit cardboard | Vacuum Cover adsorbable style, High pressure Draw fan with wind control Adjusting & noise deadening device |
|---|---|
| Style of Control Roller | Pneumatic control the upper roller, pressure roller and glue roller |
| Glue Width Adjusting | Electric adjusting |
| Driving Way | With frequency inverter |
